Higgs Boson Signal Classification
A deep learning pipeline classifying rare Higgs boson decay events (H → ZZ → 4ℓ) from overwhelming standard model backgrounds using simulated CMS Open Data.
Overview
This project focuses on identifying the Higgs boson, a fundamental particle that gives mass to other elementary particles, through its decay into two Z bosons, which subsequently decay into four leptons (H → ZZ → 4ℓ). This decay channel is often called the 'golden channel' due to its clean experimental signature, but it is extremely rare and buried under significant background processes.
Using a dataset of 218,632 simulated events based on CMS Open Data, our team constructed a binary classification pipeline to distinguish the Higgs signal from three primary background processes: ZZ → 4e, ZZ → 2e2μ, and ZZ → 4μ. The key input features for the model were the reconstructed mass of the Higgs candidate, and the masses of the two Z bosons.
The core of the project was a custom Feed-Forward Deep Neural Network (DNN) implemented in PyTorch. The architecture featured a Linear input layer, a ReLU activation hidden layer, and a Sigmoid output layer for binary classification. The model was trained using Binary Cross-Entropy Loss and the Adam optimizer over 1000 epochs, achieving a highly successful 97.3% training accuracy and 97.1% validation accuracy, demonstrating strong generalization without overfitting.
Performance evaluation involved comprehensive analysis including Receiver Operating Characteristic (ROC) curves with an Area Under Curve (AUC) of ~0.99, demonstrating exceptional signal-to-background discrimination. The project culminated in a detailed presentation and poster summarizing the methodology and physics implications.
Interactive Code Notebook
Interactive Jupyter Notebook — Scroll to view code, click 'Run' to execute and reveal outputs.
Final Build
Process
01 — Data Ingestion & Preprocessing
Extracting ROOT files and standardizing features
Loaded signal and background datasets from CMS Open Data ROOT files using uproot. Extracted key kinematic variables (Higgs_mass, Z1_mass, Z2_mass) and standardized the feature set using scikit-learn's StandardScaler for optimal neural network convergence.
02 — Model Architecture
Designing the PyTorch DNN
Constructed a custom feed-forward neural network in PyTorch, utilizing a hidden layer with ReLU activation to capture non-linear relationships in the particle kinematics, followed by a sigmoid output for binary probability scoring.
03 — Training & Optimization
Model fitting and loss minimization
Trained the network using Binary Cross-Entropy (BCE) loss and the Adam optimizer. Continuously monitored training and validation loss/accuracy across 1000 epochs to prevent overfitting and ensure robust generalization.
04 — Physics Evaluation
Analyzing model discrimination power
Evaluated the trained model using ROC curves and AUC metrics for each specific background process. Plotted DNN score distributions to visually verify the network's ability to successfully separate the rare Higgs signal from dominant standard model backgrounds.
Engineering Details
Dataset Composition
| Process Type | Decay Channel | Label | Description |
|---|---|---|---|
| Signal | H → ZZ → 4ℓ | 1.0 | Higgs boson decaying to four leptons (electrons/muons) |
| Background | ZZ → 4e | 0.0 | Standard model production of 4 electrons |
| Background | ZZ → 2e2μ | 0.0 | Standard model production of 2 electrons and 2 muons |
| Background | ZZ → 4μ | 0.0 | Standard model production of 4 muons |
Model Architecture & Hyperparameters
| Parameter | Configuration | Notes |
|---|---|---|
| Input Features | 3 | Higgs_mass, Z1_mass, Z2_mass |
| Hidden Layer | 16 nodes | ReLU activation function |
| Output Layer | 1 node | Sigmoid activation for binary classification |
| Loss Function | Binary Cross-Entropy (BCE) | Standard for binary probability tasks |
| Optimizer | Adam | Learning rate = 0.5 |
| Epochs | 1000 | With early stopping validation monitoring |
